CAT#:
Sartorius
Minisart® Cellulose Acetate
0.8µm, 28mm, 50 Filters/Unit
5.0µm, 28mm, 500 Filters/Unit
0.8µm, 28mm, 500 Filters/Unit
0.65µm, 28mm, 50 Filters/Unit
4 product variations: View Options
Product Overview
- Sterile and ready-to-use
- SFCA in many pore sizes
- Very low non-specific binding
- PVC-free
- Bidirectional use possible
Product Overview
- Bulk packs for less waste
- PVC-free
- Glueable, e.g. to tubing
- Bidirectional use possible
- Very low non-specific binding
- Many pore sizes available
Product Overview
- Bulk packs for less waste
- PVC-free
- Glueable, e.g. to tubing
- Bidirectional use possible
- Very low non-specific binding
Product Overview
- Sterile and ready-to-use
- SFCA in many pore sizes
- Very low non-specific binding
- PVC-free
- Bidirectional use possible
Technical Specifications
| Application | Clarification and particle removal of aqueous solutions such as media, buffers and sera Clarification |
| Connector Inlet | Female Luer Lock |
| Connector Outlet | Male Luer Lock |
| Filter Diameter | ⌀ 28 mm |
| Filtration Area | 6.2 cm² |
| High Flow | No |
| Filter Paper/membrane Color | Green |
| Flow Rate | ≥ 400 mL/min for water at 1 bar (14.5 psi) |
| Total Throughput | Up to 200 mL |
| Ph Range | 4.0 – 8.0 |
| Housing Material | Methacrylate butadiene styrene (MBS) |
| Membrane Material | Cellulose Acetate (CA) |
| Maximum Allowable Working Temperature | 60 °C (140 °F) |
| Maximum Operating Pressure | 4.5 bar (65 psi) |
| Operating Pressure | 4.5 bar (65 psi) |
| Bubble Point | ≥ 0.8 bar (12 psi) with water |
| Burst Pressure | ≥ 7.0 bar (102 psi) |
| Pore Size | 0.8 µm |
| Wettability | Hydrophilic |
| Brand | Minisart® NML |
| Device Type | Syringe Filters |
| Pack Size | 50 |
| Packaging | Single blister packed |
| Sample Type | Aqueous |
| Delivery Condition | Sterile |
| Sterilization Method | Gamma irradiation |
| Hold-up Volume | ≤ 100 – 150 µL |
Technical Specifications
| Application | Clarification and particle removal of aqueous solutions such as media, buffers and sera Clarification |
| Connector Inlet | Female Luer Lock |
| Connector Outlet | Male Luer Lock |
| Filter Diameter | ⌀ 28 mm |
| Filtration Area | 6.2 cm² |
| High Flow | No |
| Filter Paper/membrane Color | Brown |
| Flow Rate | ≥ 600 mL/min for water at 1 bar (14.5 psi) |
| Total Throughput | Up to 200 mL |
| Ph Range | 4.0 – 8.0 |
| Housing Material | Methacrylate butadiene styrene (MBS) |
| Membrane Material | Cellulose Acetate (CA) |
| Maximum Allowable Working Temperature | 60 °C (140 °F) |
| Maximum Operating Pressure | 4.5 bar (65 psi) |
| Operating Pressure | 4.5 bar (65 psi) |
| Bubble Point | ≥ 0.7 bar (10 psi) with water |
| Burst Pressure | ≥ 7.0 bar (102 psi) |
| Pore Size | 5 µm |
| Wettability | Hydrophilic |
| Brand | Minisart® NML |
| Device Type | Syringe Filters |
| Pack Size | 500 |
| Packaging | Bulk packed |
| Sample Type | Aqueous |
| Delivery Condition | Non-Sterile |
| Sterilization Method | Ethylene oxide Gamma irradiation |
| Hold-up Volume | ≤ 100 – 150 µL |
Technical Specifications
| Application | Clarification and particle removal of aqueous solutions such as media, buffers and sera Clarification |
| Connector Inlet | Female Luer Lock |
| Connector Outlet | Male Luer Lock |
| Filter Diameter | ⌀ 28 mm |
| Filtration Area | 6.2 cm² |
| High Flow | No |
| Filter Paper/membrane Color | Green |
| Flow Rate | ≥ 400 mL/min for water at 1 bar (14.5 psi) |
| Total Throughput | Up to 200 mL |
| Ph Range | 4.0 – 8.0 |
| Housing Material | Methacrylate butadiene styrene (MBS) |
| Membrane Material | Cellulose Acetate (CA) |
| Maximum Allowable Working Temperature | 60 °C (140 °F) |
| Maximum Operating Pressure | 4.5 bar (65 psi) |
| Operating Pressure | 4.5 bar (65 psi) |
| Bubble Point | ≥ 0.8 bar (12 psi) with water |
| Burst Pressure | ≥ 7.0 bar (102 psi) |
| Pore Size | 0.8 µm |
| Wettability | Hydrophilic |
| Brand | Minisart® NML |
| Device Type | Syringe Filters |
| Pack Size | 500 |
| Packaging | Bulk packed |
| Sample Type | Aqueous |
| Delivery Condition | Non-Sterile |
| Sterilization Method | Ethylene oxide Gamma irradiation |
| Hold-up Volume | ≤ 100 – 150 µL |
Technical Specifications
| Application | Clarification and particle removal of aqueous solutions such as media, buffers and sera |
| Application Area | Clarification Particle removal |
| Connector Inlet | Female Luer Lock |
| Connector Outlet | Male Luer Slip |
| Filter Diameter | ⌀ 28 mm |
| Filtration Area | 6.2 cm² |
| High Flow | No |
| Filter Paper/membrane Color | Pink |
| Flow Rate | ≥ 250 mL/min for water at 1 bar (14.5 psi) |
| Total Throughput | Up to 200 mL |
| Ph Range | 4.0 – 8.0 |
| Housing Material | Methacrylate butadiene styrene (MBS) |
| Membrane Material | Cellulose Acetate (CA) |
| Maximum Allowable Working Temperature | 60 °C (140 °F) |
| Maximum Operating Pressure | 4.5 bar (65 psi) |
| Operating Pressure | 4.5 bar (65 psi) |
| Bubble Point | ≥ 1.3 bar (19 psi) with water |
| Burst Pressure | ≥ 7.0 bar (102 psi) |
| Pore Size | 0.65 µm |
| Wettability | Hydrophilic |
| Brand | Minisart® NML |
| Device Type | Syringe Filters |
| Pack Size | 50 |
| Packaging | Single blister packed |
| Sample Type | Aqueous |
| Delivery Condition | Sterile |
| Sterilization Method | Ethylene oxide |
| Hold-up Volume | ≤ 100 – 150 µL |
Technical Documents
- Minisart® Syringe Filters — The Easy Choice – Clean and Safe
- Laboratory Filtration Products Catalog
- HPLC-Certificate — Minisart® Syringe Filters for Sample Preparation – reliable and ultrapure
- Minisart® Chemical Compatibility Guide
- Instructions for Use Minisart® High Flow | NML | Air | HY | Acticosart Sartorius Syringe Filters for Liquid Filtration and Venting
Technical Documents
- Minisart® Syringe Filters — The Easy Choice – Clean and Safe
- Laboratory Filtration Products Catalog
- HPLC-Certificate — Minisart® Syringe Filters for Sample Preparation – reliable and ultrapure
- Instructions for Use Minisart® High Flow | NML | Air | HY | Acticosart Sartorius Syringe Filters for Liquid Filtration and Venting
- Minisart® Chemical Compatibility Guide
Technical Documents
- Minisart® Syringe Filters — The Easy Choice – Clean and Safe
- Laboratory Filtration Products Catalog
- HPLC-Certificate — Minisart® Syringe Filters for Sample Preparation – reliable and ultrapure
- Minisart® Chemical Compatibility Guide
- Instructions for Use Minisart® High Flow | NML | Air | HY | Acticosart Sartorius Syringe Filters for Liquid Filtration and Venting
Detailed Description
Minisart® NML with surfactant-free cellulose acetate (SFCA) is the best choice for all aqueous solutions and oils with a pH of 4 - 8. Type 16569 with a pore size of 0.65 µm can be used for particle and yeast cell removal and has a male luer lock outlet. Version K is individually packed and sterilized by ethylene oxide (EO).
Individually packed and sterile Minisart® NML syringe filters are optimal for immediate usage whenever sterile filtration or clarification and cell removal under sterile conditions is needed. The SFCA membrane is the best option for leachable free filtrations and is available in many different pore sizes. The very low non-specific binding characteristics of this membrane makes it a perfect choice for biomolecule solutions. The housing is made of the acrylic resin MBS (Methacrylate butadiene styrene) which has a limited compatibility with alcohols but is free of phthalates and passes the plastic class VI test. Housing and membrane are tightly connected which allows bidirectional use.
4 Product Options
Catalog Number:
60-1856
List Price:
$275.64
Your Price:
$236.26
Specifications:
| Pore Size | 0.8µm |
| Membrane Material | Surfactant Free CA |
| Diameter | 28mm |
| Sterility | Sterile |
| Description | 0.8µm, 28mm |
| Qty/Unit | 50 Filters/Unit |
Catalog Number:
60-1879
List Price:
$1652.42
Your Price:
$1416.36
Specifications:
| Pore Size | 5µm |
| Membrane Material | CA |
| Diameter | 28mm |
| Sterility | Non-Sterile |
| Description | 5.0µm, 28mm |
| Qty/Unit | 500 Filters/Unit |
Catalog Number:
60-1858
List Price:
$1643.82
Your Price:
$1408.98
Specifications:
| Pore Size | 0.8µm |
| Membrane Material | Surfactant Free CA |
| Diameter | 28mm |
| Sterility | Non-Sterile |
| Description | 0.8µm, 28mm |
| Qty/Unit | 500 Filters/Unit |
Catalog Number:
60-1855
List Price:
$275.64
Your Price:
$236.26
Specifications:
| Pore Size | 0.65µm |
| Membrane Material | Surfactant Free CA |
| Diameter | 28mm |
| Sterility | Sterile |
| Description | 0.65µm, 28mm |
| Qty/Unit | 50 Filters/Unit |
| Catalog # | Description | Qty/Unit | Pore Size | Membrane Material | Diameter | Sterility | Price (USD) | Quantity | Add to Order | |
|---|---|---|---|---|---|---|---|---|---|---|
| 60-1855 | 0.65µm, 28mm | 50 Filters/Unit | 0.65µm | Surfactant Free CA | 28mm | Sterile | ||||
| 60-1856 | 0.8µm, 28mm | 50 Filters/Unit | 0.8µm | Surfactant Free CA | 28mm | Sterile | ||||
| 60-1858 | 0.8µm, 28mm | 500 Filters/Unit | 0.8µm | Surfactant Free CA | 28mm | Non-Sterile | ||||
| 60-1879 | 5.0µm, 28mm | 500 Filters/Unit | 5µm | CA | 28mm | Non-Sterile |
